Panorama Antennas LPB-6-60-2SP - Low-Profile Panel Antenna 5G/4G/3G/2G, 2 m CS29 Cable, SMA (m)

LPB-6-60-2SP - Low-Profile Panel Antenna 5G/4G/3G/2G, 2 m CS29 Cable, SMA (m)

The LPB-6-60 antenna is a cost-effective omnidirectional antenna for 4G/3G/2G and 5G devices operating in the frequency range of 617-960/1710-6000 MHz.

The LPB-6-60 comes with an integrated 5 mm double-shielded CS29 coaxial cable and is available with a variety of connectors.

This antenna is an ideal solution for use in industrial and residential environments with mobile modems/routers and wireless connectivity applications for machine-to-machine (M2M) communication.

The LPB-6-60 requires a conductive ground plane with a diameter of over 300 mm for optimal performance or can be mounted on a bracket.

Electrical Data

• LTE Frequencies: 617-960/1710-6000 MHz

• Max. Input Power (W): 30

• Pattern: Omnidirectional

Mechanical Data

• Available Colors: Black

• Height (mm): 82

• Diameter (mm): 48

• Operating Temperature: -40°C to +85°C

Mounting Data

• Mounting Type: Panel Mounting.
